* slike so simbolične
Blokirni ventil za manometer, pipa - rotirajoča puša, G 1/2
SKU: 102666RIE
EAN: 9095110
Blocking valve pressure gauge, Taps - rotating bushing, DIN 16270, B shape, stainless steel 1.4571, G 1/2, PN 400 bar, max. 200 °C
Used as shut-off or reducing elements for pressure gauges when measuring liquids, gases or steam.
Obrestno financiranje
- 12,07 € x 12 mesecev
- 23,61 € x 6 mesecev
- 46,71 € x 3 mesecev
Leanpay omogoča enostavne obročne nakupe preko spleta. Za obročno plačilo v košarici izberi Leanpay. Informativni izračun ne vključuje stroškov ocene tveganja.
Šifra | Min. delovna temperatura [°C] | Konektor z notranjim/zunanjim navojem | Matica | Ohišje | Max. delovna temperatura [°C] | PN [bar] | Zaloga | Cena | Nakup | Natisni |
---|---|---|---|---|---|---|---|---|---|---|
102666RIE | -20 | Stainless steel | Stainless steel | Stainless steel 1.4571 | 200 | 400 | Čas dobave: Predvidoma 3 - 5 dni | 129,16 € | ||
102665RIE | -10 | Steel | Steel | Brass | 120 | 250 | Čas dobave: Predvidoma 3 - 5 dni | 62,70 € |
Opis
Blocking valve pressure gauge, Taps - rotating bushing, DIN 16270, B shape, stainless steel 1.4571, G 1/2, PN 400 bar, max. 200 °C
Used as shut-off or reducing elements for pressure gauges when measuring liquids, gases or steam.
Tehnični podatki in specifikacije
Navoj | G 1/2 |
Min. delovna temperatura [°C] | -20 |
Max. delovna temperatura [°C] | 200 |
PN [bar] | 400 |
a/f [mm] | 27 |
Tesnilo | PTFE |
Kolo | Plastic |
Ohišje | Stainless steel 1.4571 |
Steblo ventila | Stainless steel |
Stožec ventila | Stainless steel |
Matica | Stainless steel |
Konektor z notranjim/zunanjim navojem | Stainless steel |
Različica | male / loose female and shaft for instrument holder |
