Filter z aktivnim ogljem »multifix«PC zbir.Vel. 3G 1/2
SKU: 100540RIE
EAN: 4047322131223
Active charcoal filter »multifix« with PC container, 0.005 mg/m³, Size 3, G 1/2, Input pressure max. 16 bar, Temp. max. 60 °C
For filtering odours out of compressed air.
The activated carbon absorbs the oil vapour molecules contained in the compressed air.
A separate filter route prevents activated carbon particles from entering the air flow.
Čas dobave: Predvidoma 3 - 5 dni
Povpraševanje
Filter z aktivnim ogljem »multifix«PC zbir.Vel. 3G 1/2
Element filtra: Activated carbon-POM
Merjenje pretoka: At P1 = 6 bar and pressure drop Δp = 0.2 bar
Navoj: G 1/2
Ohišje: Die-cast zinc
Posoda: Polycarbonate container
Serija: multifix
Vsebnost olja v ostanku [mg/m³]: 0.005
D [mm]: 132.1
B [mm]: 166.6
Merjenje pretoka: At P1 = 6 bar and pressure drop Δp = 0.2 bar
Navoj: G 1/2
Ohišje: Die-cast zinc
Posoda: Polycarbonate container
Serija: multifix
Vsebnost olja v ostanku [mg/m³]: 0.005
D [mm]: 132.1
B [mm]: 166.6
| Šifra | Navoj | Velikost | DN | C [mm] | A [mm] | D [mm] | B [mm] | Pretok [l/min] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 100539RIE | G 1/4 | 1 | 6 | 27.0 | 47.8 | 109.8 | 136.8 | 380 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje |  |
| 100540RIE | G 1/2 | 3 | 15 | 34.5 | 68.8 | 132.1 | 166.6 | 1500 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
Opis
Active charcoal filter »multifix« with PC container, 0.005 mg/m³, Size 3, G 1/2, Input pressure max. 16 bar, Temp. max. 60 °C
For filtering odours out of compressed air.
The activated carbon absorbs the oil vapour molecules contained in the compressed air.
A separate filter route prevents activated carbon particles from entering the air flow.
Tehnični podatki in specifikacije
| Navoj | G 1/2 |
| Max. vhodni tlak [bar] | 16 |
| Velikost | 3 |
| Tesnilo | NBR |
| Element filtra | Activated carbon-POM |
| Max. temperatura medija [°C] | 60 |
| Max. sobna temperatura [°C] | 60 |
| Pretok [l/min] | 1500 |
| DN | 15 |
| Ohišje | Die-cast zinc |
| Posoda | Polycarbonate container |
| A [mm] | 68.8 |
| B [mm] | 166.6 |
| C [mm] | 34.5 |
| D [mm] | 132.1 |
| Serija | multifix |
| Merjenje pretoka | At P1 = 6 bar and pressure drop Δp = 0.2 bar |
| Vsebnost olja v ostanku [mg/m³] | 0.005 |
