Glicerinski manometer, CrNi jeklo, G 1/2, -1 / 0 bar, Ø 100
SKU: 134031RIE
EAN: 9536400
Glycerine pressure gauge CrNi steel design, Connection, rear, eccentric, G 1/2, Goods class 1.0, Measure. range -1 / 0 bar, Ø 100
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type.
For use in the chemical/petrochemical process industry, power stations, machinery and
industrial plant engineering.
For measurements in areas with high, dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity,
also in corrosive atmosphere.
Povpraševanje
Material Prozessanschluss: CrNi steel
Položaj povezave: rear, excentrical
Povezava: G 1/2
Prednje steklo: Laminated safety glass
Spodnja/Zgornja meja območja: Vacuum
Vrsta: 233.50
| Šifra | Merilno območje min. bar | Položaj povezave | Povezava | Prednje steklo | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Razred točnosti | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 134023RIE | -1 | rear, centrical | G 1/4 | Polycarbonate | Vacuum | 0.05 | 1.6 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje |  |
| 134024RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.1 | 1.6 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134025RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134026RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134027RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 10 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134028RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134029RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 1 | 1.6 | 25 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134030RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 2 | 1.6 | 40 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134031RIE | -1 | rear, excentrical | G 1/2 | Laminated safety glass | Vacuum | 0.02 | 1.0 | 0 | 100 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 134032RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.05 | 1.0 | 2.5 | 100 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
Opis
Glycerine pressure gauge CrNi steel design, Connection, rear, eccentric, G 1/2, Goods class 1.0, Measure. range -1 / 0 bar, Ø 100
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type.
For use in the chemical/petrochemical process industry, power stations, machinery and
industrial plant engineering.
For measurements in areas with high, dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity,
also in corrosive atmosphere.
Tehnični podatki in specifikacije
| Povezava | G 1/2 |
| Položaj povezave | rear, excentrical |
| Premer [mm] | 100 |
| Vrsta | 233.50 |
| Razred točnosti | 1.0 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 100 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Material | CrNi steel |
| Prednje steklo | Laminated safety glass |
| Merilno območje min. bar | -1 |
| Stopnja rasti na območju skale - bar [bar] | 0.02 |
| Spodnja/Zgornja meja območja | Vacuum |
| Material Prozessanschluss | CrNi steel |
