Glicerinski manometer, CrNi jeklo, G 1/4, 0 - 160 bar, Ø 63
SKU: 102385RIE
EAN: 9010220
Glycerine pressure gauge, CrNi steel safety design, Connection radial bottom, G 1/4, Measurement range 0 - 160 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type, with solid baffle wall and blow-out (safety housing).
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Čas dobave: Predvidoma 3 - 5 dni
168,49 €
ali od 15,72 € / mesec
Izračunaj obrok
Obrestno financiranje
- 15,72 € x 12 mesecev
- 30,75 € x 6 mesecev
- 60,82 € x 3 mesecev
Leanpay omogoča enostavne obročne nakupe preko spleta. Za obročno plačilo v košarici izberi Leanpay. Informativni izračun ne vključuje stroškov ocene tveganja.
| Šifra | Merilno območje min. bar | Povezava | Prednje steklo | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Razred točnosti | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 102379RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 10 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 144,63 € |  | |
| 102402RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 5 | 1.0 | 160 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102376RIE | -1 | G 1/4 | Polycarbonate | Vacuum | 0.05 | 1.6 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 153,21 € | | |
| 102401RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 2 | 1.0 | 100 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102389RIE | -1 | G 1/2 | Laminated safety glass | Vacuum/Positive pressure | 0.05 | 1.0 | 1.5 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102396RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.2 | 1.0 | 10 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 310,36 € | | |
| 102384RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 5 | 1.6 | 100 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 168,49 € | | |
| 102386RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 10 | 1.6 | 250 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 168,49 € | | |
| 102397RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.5 | 1.0 | 16 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 310,36 € | | |
| 102382RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 2 | 1.6 | 40 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 144,63 € | | |
| 102404RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 10 | 1.0 | 400 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102391RIE | -1 | G 1/2 | Laminated safety glass | Vacuum/Positive pressure | 0.1 | 1.0 | 5 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102398RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.5 | 1.0 | 25 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 310,36 € | | |
| 102395RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.1 | 1.0 | 6 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 310,36 € | | |
| 102399RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 1 | 1.0 | 40 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 310,36 € | | |
| 102377RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 153,21 € | | |
| 102394RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.1 | 1.0 | 4 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102393RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 0.05 | 1.0 | 2.5 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102387RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 20 | 1.6 | 400 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 168,49 € | | |
| 102400RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 1 | 1.0 | 60 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102405RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 10 | 1.0 | 600 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102383RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 2 | 1.6 | 60 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 168,49 € | | |
| 102403RIE | 0 | G 1/2 | Laminated safety glass | Positive pressure | 5 | 1.0 | 250 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 359,66 € | | |
| 102380RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 144,63 € | | |
| 102388RIE | -1 | G 1/2 | Laminated safety glass | Vacuum | 0.02 | 1.0 | 0 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102378RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 144,63 € | | |
| 102381RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 1 | 1.6 | 25 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 144,63 € | | |
| 102392RIE | -1 | G 1/2 | Laminated safety glass | Vacuum/Positive pressure | 0.2 | 1.0 | 9 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102390RIE | -1 | G 1/2 | Laminated safety glass | Vacuum/Positive pressure | 0.1 | 1.0 | 3 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 314,85 € | | |
| 102385RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 5 | 1.6 | 160 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 168,49 € | |
Opis
Glycerine pressure gauge, CrNi steel safety design, Connection radial bottom, G 1/4, Measurement range 0 - 160 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type, with solid baffle wall and blow-out (safety housing).
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Tehnični podatki in specifikacije
| Povezava | G 1/4 |
| Položaj povezave | radial on bottom |
| Premer [mm] | 63 |
| Vrsta | 233.30 |
| Razred točnosti | 1.6 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 100 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Material | CrNi steel |
| Prednje steklo | Polycarbonate |
| Merilno območje max. bar | 160 |
| Stopnja rasti na območju skale - bar [bar] | 5 |
| Spodnja/Zgornja meja območja | Positive pressure |
| Material Prozessanschluss | CrNi steel |
