Glicerinski manometer, CrNi jeklo, G 1/4, 0 - 2.5 bar, Ø 63
SKU: 102317RIE
EAN: 9020730
Glycerine pressure gauge CrNi steel design, Connection radial bottom, G 1/4, Goods class 1.6, Measurement range 0 - 2.5 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type.
For use in the chemical/petrochemical process industry, power stations, machinery and industrial plant engineering.
For measurements in areas with high, dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Povpraševanje
Material Prozessanschluss: CrNi steel
Položaj povezave: radial on bottom
Povezava: G 1/4
Prednje steklo: Polycarbonate
Spodnja/Zgornja meja območja: Positive pressure
Vrsta: 233.50
| Šifra | Merilno območje min. bar | Povezava | Prednje steklo | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Razred točnosti | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 102308RIE | -1 | G 1/4 | Polycarbonate | Vacuum | 0.05 | 1.6 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje |  |
| 102309RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.05 | 1.6 | 0.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102310RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.1 | 1.6 | 1.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102311RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.2 | 1.6 | 3 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102312RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.2 | 1.6 | 5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102313RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.5 | 1.6 | 9 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102314RIE | -1 | G 1/4 | Polycarbonate | Vacuum/Positive pressure | 0.5 | 1.6 | 15 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102315RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.05 | 1.6 | 1 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102316RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.05 | 1.6 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
| 102317RIE | 0 | G 1/4 | Polycarbonate | Positive pressure | 0.1 | 1.6 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | Povpraševanje | Povpraševanje | |
Opis
Glycerine pressure gauge CrNi steel design, Connection radial bottom, G 1/4, Goods class 1.6, Measurement range 0 - 2.5 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type.
For use in the chemical/petrochemical process industry, power stations, machinery and industrial plant engineering.
For measurements in areas with high, dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Tehnični podatki in specifikacije
| Povezava | G 1/4 |
| Položaj povezave | radial on bottom |
| Premer [mm] | 63 |
| Vrsta | 233.50 |
| Razred točnosti | 1.6 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 100 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Material | CrNi steel |
| Prednje steklo | Polycarbonate |
| Merilno območje max. bar | 2.5 |
| Stopnja rasti na območju skale - bar [bar] | 0.1 |
| Spodnja/Zgornja meja območja | Positive pressure |
| Material Prozessanschluss | CrNi steel |
