* slike so simbolične
Glicerinski manometer, CrNi jeklo, G 1/4, -1 / 0 bar, Ø 63
SKU: 102376RIE
EAN: 9020420
Glycerine pressure gauge, CrNi steel safety design, Connection radial bottom, G 1/4, Measurement range -1 / 0 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type, with solid baffle wall and blow-out (safety housing).
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Opis
Glycerine pressure gauge, CrNi steel safety design, Connection radial bottom, G 1/4, Measurement range -1 / 0 bar, Ø 63
Glycerine-filled bourdon-tube pressure gauge, CrNi steel type, with solid baffle wall and blow-out (safety housing).
Suitable for gaseous or liquid, corrosive and crystallising media which do not have high viscosity, also in corrosive atmosphere.
Tehnični podatki in specifikacije
Povezava | G 1/4 |
Položaj povezave | radial on bottom |
Premer [mm] | 63 |
Vrsta | 233.30 |
Razred točnosti | 1.6 |
Min. temperatura medija [°C] | -20 |
Max. temperatura medija [°C] | 100 |
Min. sobna temperatura [°C] | -20 |
Max. sobna temperatura [°C] | 60 |
Material | CrNi steel |
Prednje steklo | Polycarbonate |
Merilno območje min. bar | -1 |
Stopnja rasti na območju skale - bar [bar] | 0.05 |
Spodnja/Zgornja meja območja | Vacuum |
Material Prozessanschluss | CrNi steel |
