Glicerinski manometer »pressure line« G1/2, 0-16 bar/230 psi
SKU: 116320RIE
EAN: 4047322176927
Glycerine press. gauge »pressure line« Connection radial bottom, G 1/2, Goods class 1.6, Measurement range 0-16 bar/230 psi, Ø 100
Low-priced series of high-quality, glycerine-filled pressure gauges with stainless steel housing for all applications involving measurements in areas with high dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Zaloga po poslovalnicah
- Ljubljana Na zalogi
- Maribor Na zalogi
| Šifra | Povezava | Stopnja rasti na območju skale - bar [bar] | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|
| 116308RIE | G 1/4 | 0.2 | 10 | 63 | Na zalogi | 28,18 € |  | |
| 116307RIE | G 1/4 | 0.2 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 28,18 € | | |
| 116322RIE | G 1/2 | 1 | 40 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 48,30 € | | |
| 116312RIE | G 1/4 | 2 | 60 | 63 | Na zalogi | 28,18 € | | |
| 116314RIE | G 1/4 | 10 | 160 | 63 | Na zalogi | 28,18 € | | |
| 116311RIE | G 1/4 | 1 | 40 | 63 | Na zalogi | 28,18 € | | |
| 116323RIE | G 1/2 | 5 | 250 | 100 | Na zalogi | 50,62 € | | |
| 116316RIE | G 1/4 | 10 | 400 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 31,65 € | | |
| 116313RIE | G 1/4 | 5 | 100 | 63 | Na zalogi | 28,18 € | | |
| 116306RIE | G 1/4 | 0.1 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 28,18 € | | |
| 116319RIE | G 1/2 | 0.2 | 10 | 100 | Na zalogi | 48,30 € | | |
| 116324RIE | G 1/2 | 10 | 400 | 100 | Na zalogi | 50,62 € | | |
| 116318RIE | G 1/2 | 0.1 | 6 | 100 | Na zalogi | 48,30 € | | |
| 116317RIE | G 1/4 | 20 | 600 | 63 | Na zalogi | 31,65 € | | |
| 116321RIE | G 1/2 | 1 | 25 | 100 | Na zalogi | 48,30 € | | |
| 116310RIE | G 1/4 | 1 | 25 | 63 | Na zalogi | 28,18 € | | |
| 116305RIE | G 1/4 | 0.1 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 28,18 € | | |
| 116315RIE | G 1/4 | 10 | 250 | 63 | Na zalogi | 31,65 € | | |
| 116309RIE | G 1/4 | 0.5 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 28,18 € | | |
| 116320RIE | G 1/2 | 0.5 | 16 | 100 | Na zalogi | 48,30 € | |
Opis
Glycerine press. gauge »pressure line« Connection radial bottom, G 1/2, Goods class 1.6, Measurement range 0-16 bar/230 psi, Ø 100
Low-priced series of high-quality, glycerine-filled pressure gauges with stainless steel housing for all applications involving measurements in areas with high dynamic pressure loads and vibration levels.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Tehnični podatki in specifikacije
| Povezava | G 1/2 |
| Položaj povezave | radial on bottom |
| Premer [mm] | 100 |
| Razred točnosti | 1.6 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 60 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Prednje steklo | Glass |
| Ohišje | Stainless steel |
| Merilni element | Brass |
| Premikanje | Brass |
| Merilno območje max. bar | 16 |
| Stopnja rasti na območju skale - bar [bar] | 0.5 |
| Različica | Bourdon-tube pressure gauge with glycerine filling |
| Material Prozessanschluss | Copper alloy |
