ManometerCrNi jeklocentr. priklop zadaj G 1/4, -1/0 bar, Ø63
SKU: 102507RIE
EAN: 8910731
Pressure gauge CrNi steel design, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range -1 / 0 bar, Ø 63
Bourdon-tube pressure gauge, CrNi steel type, all stainless steel.
Suitable for gaseous or liquid media which do not have high viscosity and do not crystallise,
also in corrosive atmosphere.
Čas dobave: Predvidoma 3 - 5 dni
151,16 €
ali od 14,13 € / mesec
Izračunaj obrok
Obrestno financiranje
- 14,13 € x 12 mesecev
- 27,64 € x 6 mesecev
- 54,67 € x 3 mesecev
Leanpay omogoča enostavne obročne nakupe preko spleta. Za obročno plačilo v košarici izberi Leanpay. Informativni izračun ne vključuje stroškov ocene tveganja.
| Šifra | Merilno območje min. bar | Opis | Položaj povezave | Povezava | Prednje steklo | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Razred točnosti | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 102511RIE | 0 | Pressure gauge Ø 63 mm, G 1/4 ET, 0 - 25 bar | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 1 | 1.6 | 25 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 147,02 € |  | |
| 102512RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 2 | 1.6 | 40 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 147,02 € | | ||
| 102510RIE | 0 | Pressure gauge Ø 63 mm, G 1/4 ET, 0 - 6 bar | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 147,02 € | | |
| 102515RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.1 | 1.0 | 6 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 235,48 € | | ||
| 102516RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.2 | 1.0 | 10 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 235,48 € | | ||
| 101202RIE | 0 | Pressure gauge Ø 63 mm, G 1/4 ET, 0 - 16 bar | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 147,02 € | | |
| 102513RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 5 | 1.6 | 100 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 177,96 € | | ||
| 102508RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.1 | 1.6 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 151,16 € | | ||
| 102509RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.2 | 1.6 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 151,16 € | | ||
| 134044RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 1 | 1.0 | 40 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 118691RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.1 | 1.0 | 4 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 131496RIE | -1 | rear, excentrical | G 1/2 | Laminated safety glass | Vacuum | 0.02 | 1.0 | 0 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 134042RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.5 | 1.0 | 16 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 134040RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.05 | 1.0 | 2.5 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 101201RIE | 0 | Pressure gauge Ø 63 mm, G 1/4 ET, 0 - 10 bar | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 0.5 | 1.6 | 10 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 147,02 € | | |
| 102514RIE | 0 | rear, centrical | G 1/4 | Polycarbonate | Positive pressure | 10 | 1.6 | 250 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 177,96 € | | ||
| 134043RIE | 0 | rear, excentrical | G 1/2 | Laminated safety glass | Positive pressure | 0.5 | 1.0 | 25 | 100 | Čas dobave: Predvidoma 3 - 5 dni | 243,65 € | | ||
| 102507RIE | -1 | rear, centrical | G 1/4 | Polycarbonate | Vacuum | 0.05 | 1.6 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 151,16 € | |
Opis
Pressure gauge CrNi steel design, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range -1 / 0 bar, Ø 63
Bourdon-tube pressure gauge, CrNi steel type, all stainless steel.
Suitable for gaseous or liquid media which do not have high viscosity and do not crystallise,
also in corrosive atmosphere.
Tehnični podatki in specifikacije
| Povezava | G 1/4 |
| Položaj povezave | rear, centrical |
| Premer [mm] | 63 |
| Vrsta | 232.50 |
| Razred točnosti | 1.6 |
| Min. temperatura medija [°C] | -40 |
| Max. temperatura medija [°C] | 200 |
| Min. sobna temperatura [°C] | -40 |
| Max. sobna temperatura [°C] | 60 |
| Material | CrNi steel |
| Prednje steklo | Polycarbonate |
| Merilno območje min. bar | -1 |
| Stopnja rasti na območju skale - bar [bar] | 0.05 |
| Spodnja/Zgornja meja območja | Vacuum |
| Material Prozessanschluss | CrNi steel |
