Okrogli cilinder, delujoč v dveh smereh, bat Ø 20, hod 250, G 1/8
SKU: 105812RIE
EAN: 4047322385794
Round cylinder, ISO 6432, double-acting, Magnet, Piston Ø 20, Stroke 250, G 1/8, Working pressure max. 10 bar, Temp. -10°C to 80°C
Single and double-acting cylinders, with magnetic piston.
Suitable for filtered, unlubricated or lubricated compressed air.
If lubrication is used, it must be continuous.
Obrestno financiranje
- 17,48 € x 6 mesecev
- 34,61 € x 3 mesecev
Leanpay omogoča enostavne obročne nakupe preko spleta. Za obročno plačilo v košarici izberi Leanpay. Informativni izračun ne vključuje stroškov ocene tveganja.
| Šifra | Navoj na batnici | Povezava | Bat Ø [mm] | Stroke [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|
| 105815RIE | M10x1,25 | G 1/8 | 25 | 50 | Čas dobave 3 - 5 dni | 73,33 € |  | |
| 105807RIE | M8 | G 1/8 | 20 | 80 | Čas dobave 3 - 5 dni | 68,33 € | | |
| 105819RIE | M10x1,25 | G 1/8 | 25 | 160 | Čas dobave 3 - 5 dni | 86,64 € | | |
| 105813RIE | M10x1,25 | G 1/8 | 25 | 10 | Čas dobave 3 - 5 dni | 68,82 € | | |
| 105805RIE | M8 | G 1/8 | 20 | 25 | Čas dobave 3 - 5 dni | 63,34 € | | |
| 105796RIE | M6 | M5 | 16 | 10 | Čas dobave 3 - 5 dni | 56,69 € | | |
| 105817RIE | M10x1,25 | G 1/8 | 25 | 100 | Čas dobave 3 - 5 dni | 77,91 € | | |
| 105803RIE | M6 | M5 | 16 | 200 | Čas dobave 3 - 5 dni | 71,34 € | | |
| 105804RIE | M8 | G 1/8 | 20 | 10 | Čas dobave 3 - 5 dni | 62,48 € | | |
| 105816RIE | M10x1,25 | G 1/8 | 25 | 80 | Čas dobave 3 - 5 dni | 74,07 € | | |
| 105797RIE | M6 | M5 | 16 | 25 | Čas dobave 3 - 5 dni | 58,02 € | | |
| 105801RIE | M6 | M5 | 16 | 125 | Čas dobave 3 - 5 dni | 65,65 € | | |
| 105808RIE | M8 | G 1/8 | 20 | 100 | Čas dobave 3 - 5 dni | 69,78 € | | |
| 105798RIE | M6 | M5 | 16 | 50 | Čas dobave 3 - 5 dni | 60,63 € | | |
| 105811RIE | M8 | G 1/8 | 20 | 200 | Čas dobave 3 - 5 dni | 79,65 € | | |
| 105810RIE | M8 | G 1/8 | 20 | 160 | Čas dobave 3 - 5 dni | 75,71 € | | |
| 105821RIE | M10x1,25 | G 1/8 | 25 | 250 | Čas dobave 3 - 5 dni | 111,45 € | | |
| 105802RIE | M6 | M5 | 16 | 160 | Čas dobave 3 - 5 dni | 68,97 € | | |
| 105818RIE | M10x1,25 | G 1/8 | 25 | 125 | Čas dobave 3 - 5 dni | 79,95 € | | |
| 105814RIE | M10x1,25 | G 1/8 | 25 | 25 | Čas dobave 3 - 5 dni | 70,20 € | | |
| 105799RIE | M6 | M5 | 16 | 80 | Čas dobave 3 - 5 dni | 62,32 € | | |
| 105800RIE | M6 | M5 | 16 | 100 | Čas dobave 3 - 5 dni | 64,20 € | | |
| 105820RIE | M10x1,25 | G 1/8 | 25 | 200 | Čas dobave 3 - 5 dni | 90,72 € | | |
| 105809RIE | M8 | G 1/8 | 20 | 125 | Čas dobave 3 - 5 dni | 71,62 € | | |
| 105806RIE | M8 | G 1/8 | 20 | 50 | Čas dobave 3 - 5 dni | 65,41 € | | |
| 105812RIE | M8 | G 1/8 | 20 | 250 | Čas dobave 3 - 5 dni | 97,64 € | |
Opis
Round cylinder, ISO 6432, double-acting, Magnet, Piston Ø 20, Stroke 250, G 1/8, Working pressure max. 10 bar, Temp. -10°C to 80°C
Single and double-acting cylinders, with magnetic piston.
Suitable for filtered, unlubricated or lubricated compressed air.
If lubrication is used, it must be continuous.
Tehnični podatki in specifikacije
| Min. nastavljeni tlak [bar] | 0.6 |
| Magnet | with magnet |
| Ffunkcija | double-acting |
| Standard | acc. to ISO 6432 |
| Cushioning | cushioned |
| Gewinde Kolbenstange | male piston rod |
| Max. delovni tlak [bar] | 10 |
| Min. temperaturno območje [°C] | -10 |
| Max. temperaturno območje [°C] | 80 |
| Tesnilo | NBR |
| Ovoj | Stainless steel 1.4301 |
| Oblika | Flanged joint between stainless steel barrel and heads |
| Bat Ø [mm] | 20 |
| Stroke [mm] | 250 |
| Povezava | G 1/8 |
| Batnica | C45 steel, hard chrome-plated |
| Navoj na batnici | M8 |
| Bat | Synthetic (acetal) resin |
