Standardni manometer, priklop zadaj, G 1/4, 0 - 4 bar, Ø 100
SKU: 102011RIE
EAN: 4047322065979
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/4, Goods class 2.5, Measurement range 0 - 4 bar, Ø 100
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Čas dobave 3 - 5 dni
25,61 €
| Šifra | Merilno območje min. bar | Ohišje | Referenčni kazalnik | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Razred točnosti | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 102014 | 0 | Sheet steel | red | Positive pressure | 0.5 | 1.6 | 16 | 100 | Čas dobave 3 - 5 dni | 25,61 € |  | |
| 101999 | 0 | Plastic | red | Positive pressure | 0.05 | 2.5 | 1.6 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102006 | 0 | Plastic | red | Positive pressure | 1 | 1.6 | 40 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102001 | 0 | Plastic | red | Positive pressure | 0.1 | 1.6 | 4 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 101998 | 0 | Plastic | red | Positive pressure | 0.02 | 2.5 | 1 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102003 | 0 | Plastic | red | Positive pressure | 0.2 | 1.6 | 10 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102005 | 0 | Plastic | red | Positive pressure | 0.5 | 2.5 | 25 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102013 | 0 | Sheet steel | red | Positive pressure | 0.2 | 1.6 | 10 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102004 | 0 | Plastic | red | Positive pressure | 0.5 | 1.6 | 16 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102000 | 0 | Plastic | red | Positive pressure | 0.05 | 1.6 | 2.5 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102010 | 0 | Sheet steel | red | Positive pressure | 0.05 | 1.6 | 2.5 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102012 | 0 | Sheet steel | red | Positive pressure | 0.1 | 2.5 | 6 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102009 | 0 | Sheet steel | red | Positive pressure | 0.05 | 1.6 | 1.6 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 101997 | -1 | Plastic | - | Vacuum | 0.02 | 2.5 | 0 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102008 | 0 | Sheet steel | red | Positive pressure | 0.02 | 1.6 | 1 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102015 | 0 | Sheet steel | red | Positive pressure | 0.5 | 2.5 | 25 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102002 | 0 | Plastic | red | Positive pressure | 0.1 | 1.6 | 6 | 80 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102007 | -1 | Sheet steel | - | Vacuum | 0.02 | 1.6 | 0 | 100 | Čas dobave 3 - 5 dni | 25,61 € | | |
| 102011 | 0 | Sheet steel | red | Positive pressure | 0.1 | 2.5 | 4 | 100 | Čas dobave 3 - 5 dni | 25,61 € | |
Opis
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/4, Goods class 2.5, Measurement range 0 - 4 bar, Ø 100
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Tehnični podatki in specifikacije
| Povezava | G 1/4 |
| Položaj povezave | rear, centrical |
| Premer [mm] | 100 |
| Vrsta | 111.12 |
| Razred točnosti | 2.5 |
| Min. temperatura medija [°C] | -20 |
| Max. temperatura medija [°C] | 60 |
| Min. sobna temperatura [°C] | -20 |
| Max. sobna temperatura [°C] | 60 |
| Ohišje | Sheet steel |
| Merilni element | Copper alloy |
| Premikanje | Copper alloy |
| Prednje steklo | Transparent plastic |
| Merilno območje max. bar | 4 |
| Stopnja rasti na območju skale - bar [bar] | 0.1 |
| Spodnja/Zgornja meja območja | Positive pressure |
| Referenčni kazalnik | red |
| Material Prozessanschluss | Copper alloy |
