Standardni manometer, priklop zadaj, G 1/8, 0 - 10 bar, Ø 40
SKU: 101816RIE
EAN: 12401544
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/8, Goods class 1.6, Measurement range 0 - 10 bar, Ø 40
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Šifra | Merilno območje min. bar | Povezava | Spodnja/Zgornja meja območja | Razred točnosti | Stopnja rasti na območju skale - bar [bar] | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
---|---|---|---|---|---|---|---|---|---|---|---|
101843RIE | 0 | G 1/4 | Positive pressure | 1.6 | 2 | 60 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101829RIE | 0 | G 1/4 | Positive pressure | 1.6 | 2 | 40 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101817RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.5 | 16 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101831RIE | 0 | G 1/4 | Positive pressure | 2.5 | 5 | 100 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101842RIE | 0 | G 1/4 | Positive pressure | 1.6 | 2 | 40 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101821RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.05 | 1 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101845RIE | 0 | G 1/4 | Positive pressure | 1.6 | 5 | 160 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101839RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.5 | 10 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101844RIE | 0 | G 1/4 | Positive pressure | 1.6 | 5 | 100 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101812RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.05 | 1.6 | 40 | Na zalogi | 13,63 € | ||
101834RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.05 | 1 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101832RIE | -1 | G 1/4 | Vacuum | 1.6 | 0.05 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101818RIE | 0 | G 1/8 | Positive pressure | 1.6 | 1 | 25 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101810RIE | -1 | G 1/8 | Vacuum | 1.6 | 0.05 | 0 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101838RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.2 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101826RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.5 | 10 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101825RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.2 | 6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101837RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.2 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101828RIE | 0 | G 1/4 | Positive pressure | 1.6 | 1 | 25 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101836RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.1 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101819RIE | 0 | G 1/8 | Positive pressure | 1.6 | 2 | 40 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101814RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.2 | 4 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101827RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.5 | 16 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101847RIE | 0 | G 1/4 | Positive pressure | 2.5 | 10 | 315 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101846RIE | 0 | G 1/4 | Positive pressure | 1.6 | 10 | 250 | 63 | Na zalogi | 16,74 € | ||
101815RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.2 | 6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101840RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.5 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101848RIE | 0 | G 1/4 | Positive pressure | 1.6 | 20 | 400 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101833RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.02 | 0.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101823RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.1 | 2.5 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101824RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.2 | 4 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101813RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.1 | 2.5 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € | ||
101822RIE | 0 | G 1/4 | Positive pressure | 1.6 | 0.05 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101841RIE | 0 | G 1/4 | Positive pressure | 1.6 | 1 | 25 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101820RIE | -1 | G 1/4 | Vacuum | 1.6 | 0.05 | 0 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101830RIE | 0 | G 1/4 | Positive pressure | 2.5 | 2 | 60 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 16,74 € | ||
101835RIE | 0 | G 1/4 | Positive pressure | 2.5 | 0.05 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 14,20 € | ||
101816RIE | 0 | G 1/8 | Positive pressure | 1.6 | 0.5 | 10 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 13,63 € |
Opis
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/8, Goods class 1.6, Measurement range 0 - 10 bar, Ø 40
Bourdon-tube pressure gauge in standard design.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Tehnični podatki in specifikacije
Povezava | G 1/8 |
Položaj povezave | rear, centrical |
Premer [mm] | 40 |
Vrsta | 111.12 |
Razred točnosti | 1.6 |
Min. temperatura medija [°C] | -20 |
Max. temperatura medija [°C] | 60 |
Min. sobna temperatura [°C] | -20 |
Max. sobna temperatura [°C] | 60 |
Ohišje | Sheet steel |
Merilni element | Copper alloy |
Premikanje | Copper alloy |
Prednje steklo | Transparent plastic |
Merilno območje max. bar | 10 |
Stopnja rasti na območju skale - bar [bar] | 0.5 |
Spodnja/Zgornja meja območja | Positive pressure |
Material Prozessanschluss | Copper alloy |
