Standardni manometer, sprednji obroč, G 1/4, 0-4 bar, Ø 63
SKU: 101904RIE
EAN: 7636216
Standard pressure gauge with front ring, black, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0-4 bar, Ø 63
Bourdon-tube pressure gauge in standard design,
either with panel-mounting bezel made of chrome-plated or black sheet steel or
with 3-hole bezel made of chrome-plated sheet steel.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Šifra | Merilno območje min. bar | Povezava | Spodnja/Zgornja meja območja | Stopnja rasti na območju skale - bar [bar] | Merilno območje max. bar | Premer [mm] | Zaloga | Cena | Nakup | Natisni |
---|---|---|---|---|---|---|---|---|---|---|
101892RIE | 0 | G 1/4 | Positive pressure | 0.1 | 2.5 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101901RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101908RIE | 0 | G 1/4 | Positive pressure | 1 | 25 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101888RIE | 0 | G 1/8 | Positive pressure | 2 | 40 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101887RIE | 0 | G 1/8 | Positive pressure | 1 | 25 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101909RIE | 0 | G 1/4 | Positive pressure | 2 | 40 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101896RIE | 0 | G 1/4 | Positive pressure | 0.5 | 16 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101895RIE | 0 | G 1/4 | Positive pressure | 0.5 | 10 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101886RIE | 0 | G 1/8 | Positive pressure | 0.5 | 16 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101899RIE | 0 | G 1/4 | Positive pressure | 2 | 60 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101894RIE | 0 | G 1/4 | Positive pressure | 0.2 | 6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101902RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1.6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101885RIE | 0 | G 1/8 | Positive pressure | 0.5 | 10 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101881RIE | 0 | G 1/8 | Positive pressure | 0.05 | 1.6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101893RIE | 0 | G 1/4 | Positive pressure | 0.2 | 4 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101891RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1.6 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101883RIE | 0 | G 1/8 | Positive pressure | 0.2 | 4 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101905RIE | 0 | G 1/4 | Positive pressure | 0.2 | 6 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101879RIE | -1 | G 1/8 | Vacuum | 0.05 | 0 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101907RIE | 0 | G 1/4 | Positive pressure | 0.5 | 16 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101880RIE | 0 | G 1/8 | Positive pressure | 0.05 | 1 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101906RIE | 0 | G 1/4 | Positive pressure | 0.5 | 10 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101884RIE | 0 | G 1/8 | Positive pressure | 0.2 | 6 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101910RIE | 0 | G 1/4 | Positive pressure | 2 | 60 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101900RIE | -1 | G 1/4 | Vacuum | 0.05 | 0 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101897RIE | 0 | G 1/4 | Positive pressure | 1 | 25 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101903RIE | 0 | G 1/4 | Positive pressure | 0.1 | 2.5 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101890RIE | 0 | G 1/4 | Positive pressure | 0.05 | 1 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101898RIE | 0 | G 1/4 | Positive pressure | 2 | 40 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101882RIE | 0 | G 1/8 | Positive pressure | 0.1 | 2.5 | 40 | Čas dobave: Predvidoma 3 - 5 dni | 21,81 € | ||
101889RIE | -1 | G 1/4 | Vacuum | 0.05 | 0 | 50 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € | ||
101904RIE | 0 | G 1/4 | Positive pressure | 0.2 | 4 | 63 | Čas dobave: Predvidoma 3 - 5 dni | 23,94 € |
Opis
Standard pressure gauge with front ring, black, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0-4 bar, Ø 63
Bourdon-tube pressure gauge in standard design,
either with panel-mounting bezel made of chrome-plated or black sheet steel or
with 3-hole bezel made of chrome-plated sheet steel.
Suitable for gaseous or liquid media which do not corrode copper alloy,
do not have high viscosity and do not crystallise.
Tehnični podatki in specifikacije
Povezava | G 1/4 |
Položaj povezave | rear, centrical |
Premer [mm] | 63 |
Vrsta | 111.12 |
Razred točnosti | 1.6 |
Min. temperatura medija [°C] | -20 |
Max. temperatura medija [°C] | 60 |
Min. sobna temperatura [°C] | -20 |
Max. sobna temperatura [°C] | 60 |
Ohišje | Sheet steel |
Merilni element | Copper alloy |
Premikanje | Copper alloy |
Prednje steklo | Transparent plastic |
Merilno območje max. bar | 4 |
Stopnja rasti na območju skale - bar [bar] | 0.2 |
Spodnja/Zgornja meja območja | Positive pressure |
Material Prozessanschluss | Copper alloy |
