Vranostna vrtljiva spojka I.D. 6, ISO 6150 C, G3/8 Z.N.modra slika
Vranostna vrtljiva spojka I.D. 6, ISO 6150 C, G3/8 Z.N.modra slika

* slike so simbolične

Vranostna vrtljiva spojka I.D. 6, ISO 6150 C, G3/8 Z.N.modra

SKU: 141889RIE
EAN: 4047322565042

Captive swivel safety coupling I.D. 6, ISO 6150 C, Steel, 2-stage, G 3/8 ET, blue, max. 25 bar, Temp. -15 °C to 200 °C

High quality, robust and long lifetime one-hand rotation secure coupling.

A secure connection is made by pushing in the plug-in nipple that clicks in audibly. Uncoupling is done by rotating the sleeve anti-clockwise. For this, the pending pressure in the coupling and line are vented, however the plug-in nipple is not completely released via a safety latch.

The plug-in nipple can only be pulled out after a clockwise rotation of the sleeve. The colour and shape coding of the coupling and plug-in nipple makes it possible only to couple to the same colours.

This coupling meets ISO standard DIN EN ISO 4414, EN 983.

Areas of application: Pneumatic system, machine and plant engineering, measurement, monitoring and control systems, manufacturing industry, workshops, automotive, mining.

Čas dobave 3 - 5 dni
56,93 €
ali od 10,43 € / mesec
Izračunaj obrok
leanpay logo
Obrestno financiranje
  • 10,43 € x 6 mesecev
  • 20,64 € x 3 mesecev

Leanpay omogoča enostavne obročne nakupe preko spleta. Za obročno plačilo v košarici izberi Leanpay. Informativni izračun ne vključuje stroškov ocene tveganja.

Primerjaj z ostalimi
Šifra Barva Povezava Zaloga Cena Nakup Natisni
141876RIE Gray G 3/8 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141862RIE Yellow G 1/4 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141850RIE Red G 3/8 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141875RIE Gray G 1/4 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141849RIE Red G 1/4 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141863RIE Yellow G 3/8 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141888RIE Blue G 1/4 ET
Čas dobave 3 - 5 dni
56,93 € Natisni
141889RIE Blue G 3/8 ET
Čas dobave 3 - 5 dni
56,93 € Natisni

Opis

Captive swivel safety coupling I.D. 6, ISO 6150 C, Steel, 2-stage, G 3/8 ET, blue, max. 25 bar, Temp. -15 °C to 200 °C

High quality, robust and long lifetime one-hand rotation secure coupling.

A secure connection is made by pushing in the plug-in nipple that clicks in audibly. Uncoupling is done by rotating the sleeve anti-clockwise. For this, the pending pressure in the coupling and line are vented, however the plug-in nipple is not completely released via a safety latch.

The plug-in nipple can only be pulled out after a clockwise rotation of the sleeve. The colour and shape coding of the coupling and plug-in nipple makes it possible only to couple to the same colours.

This coupling meets ISO standard DIN EN ISO 4414, EN 983.

Areas of application: Pneumatic system, machine and plant engineering, measurement, monitoring and control systems, manufacturing industry, workshops, automotive, mining.

Tehnični podatki in specifikacije

DN 6
Povezava G 3/8 ET
Barva Blue
a/f [mm] 22
Dolžina [mm] 64.0
Delovni tlak max. 25 bar / max. 16 bar when attaching / detaching
Min. temperaturno območje [°C] -15
Max. temperaturno območje [°C] 200
Ohišje Steel, QPQ treated
Tesnilo FKM
Pretok 630 l/min (air)
Vzmet Stainless steel
Rokav Galvanised steel, painted colored
Navojni kos Galvanised steel
Ventil Polyphenylene sulfide (PPS)
Merjenje pretoka at 6 bar and Δp = 0.5 bar
Vtični profil acc. ISO 6150 C
