Zapiralni čepi z inbus vijakom brez roba, G 1/2
SKU: 136447RIE
EAN: 4047322505512
Locking screw Hexagonal socket without flange G 1/2nickel-plated brass, Max. working pressure 25 bar, Max. operating temp. 150 °C
Suitable for air, water, oil, steam, etc.
Čas dobave: Predvidoma 3 - 5 dni
2,95 €
| Šifra | Navoj | L1 [mm] | a/f [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|---|
| 136451RIE | G 1 1/2 hexagon socket head | 22.0 | 24 | Čas dobave: Predvidoma 3 - 5 dni | 38,74 € |  | |
| 136444RIE | G 1/8 hexagon socket head | 8.0 | 5 | Čas dobave: Predvidoma 3 - 5 dni | 1,84 € | | |
| 136449RIE | G 1 hexagon socket head | 18.0 | 17 | Čas dobave: Predvidoma 3 - 5 dni | 13,97 € | | |
| 136442RIE | M12x1.5 hexagon socket head | 8.0 | 6 | Čas dobave: Predvidoma 3 - 5 dni | 1,77 € | | |
| 136440RIE | M8x0.75 hexagon socket head | 8.0 | 4 | Čas dobave: Predvidoma 3 - 5 dni | 1,60 € | | |
| 136448RIE | G 3/4 hexagon socket head | 16.0 | 12 | Čas dobave: Predvidoma 3 - 5 dni | 10,42 € | | |
| 136452RIE | G 2 hexagon socket head | 24.0 | 32 | Čas dobave: Predvidoma 3 - 5 dni | 59,18 € | | |
| 136443RIE | M14x1.5 hexagon socket head | 10.0 | 7 | Čas dobave: Predvidoma 3 - 5 dni | 1,82 € | | |
| 136446RIE | G 3/8 hexagon socket head | 12.0 | 8 | Čas dobave: Predvidoma 3 - 5 dni | 2,79 € | | |
| 136450RIE | G 1 1/4 hexagon socket head | 20.0 | 22 | Čas dobave: Predvidoma 3 - 5 dni | 25,41 € | | |
| 136441RIE | M10x1.0 hexagon socket head | 8.0 | 5 | Čas dobave: Predvidoma 3 - 5 dni | 1,65 € | | |
| 136445RIE | G 1/4 hexagon socket head | 10.0 | 7 | Čas dobave: Predvidoma 3 - 5 dni | 1,98 € | | |
| 136447RIE | G 1/2 hexagon socket head | 14.0 | 10 | Čas dobave: Predvidoma 3 - 5 dni | 2,95 € | |
Opis
Locking screw Hexagonal socket without flange G 1/2nickel-plated brass, Max. working pressure 25 bar, Max. operating temp. 150 °C
Suitable for air, water, oil, steam, etc.
Tehnični podatki in specifikacije
| Max. delovni tlak [bar] | 25 |
| Max. delovna temperatura [°C] | 150 |
| Material | Nickel-plated brass CW614N |
| Navoj | G 1/2 hexagon socket head |
| L1 [mm] | 14.0 |
| a/f [mm] | 10 |
