Dušilec z vtičem bradavico, Blue serija", 6
SKU: 109938RIE
EAN: 4047322391818
Silencer with plug nipple, »Blue Series«, plug nipple 6 mm, pmax short term 15bar, Plastic / nickel-plated brassPush-in fittings series manufactured in plastic and nickel-plated brass.
All parts are suitable for use with hoses, tubes or pipes made of plastic and copper.
Only recommended for use in combination with quick connectors of the »Blue Series«. Suitability testing for use with other series is the responsibility of the user.
Čas dobave: Predvidoma 3 - 5 dni
4,90 €
| Šifra | Priključek [mm] | L1 [mm] | Zaloga | Cena | Nakup | Natisni |
|---|---|---|---|---|---|---|
| 109939RIE | 8 | 45.0 | Čas dobave: Predvidoma 3 - 5 dni | 5,53 € |  | |
| 109941RIE | 12 | 81.5 | Čas dobave: Predvidoma 3 - 5 dni | 9,58 € | | |
| 109940RIE | 10 | 58.0 | Čas dobave: Predvidoma 3 - 5 dni | 7,92 € | | |
| 109938RIE | 6 | 46.5 | Čas dobave: Predvidoma 3 - 5 dni | 4,90 € | |
Opis
Push-in fittings series manufactured in plastic and nickel-plated brass.
All parts are suitable for use with hoses, tubes or pipes made of plastic and copper.
Only recommended for use in combination with quick connectors of the »Blue Series«. Suitability testing for use with other series is the responsibility of the user.
Tehnični podatki in specifikacije
| Serija | Blue series |
| Max. working pressure short term [bar] | 15 |
| Min. delovni tlak [bar] | -0.95 |
| Max. delovni tlak [bar] | 10 |
| Max. temperaturno območje [°C] | 80 |
| Min. temperaturno območje [°C] | -20 |
| Srednje | Compressed air, neutral and safe gases and liquids |
| L1 [mm] | 46.5 |
| Priključek [mm] | 6 |
| Material | Plastic and nickel-plated brass |
