Hitre spojke I.D. 7.2,  zunanji navoj medenina, cev I.D. 8, M12x1 slika
Hitre spojke I.D. 7.2,  zunanji navoj medenina, cev I.D. 8, M12x1 slika

* slike so simbolične

Hitre spojke I.D. 7.2, zunanji navoj medenina, cev I.D. 8, M12x1

SKU: 107230RIE
EAN: 4047322285391

Quick-connect coupling I.D. 7.2, bright brass, Sleeve I.D. 8, Bulkhead thread M12x1, Operating pre. 0-35 bar, Temp. -20°C to 100°C

"

Universal, one-hand quick disconnect couplings, one side sealing, suitable for a wide range of tasks and applications!

The closed sleeve protects the coupling from dirt.

To prevent injuries or a ""whiplash"" effect, we recommend that the plug-in nipple is held with one hand during uncoupling.

These quick disconnect couplings are not suitable for direct attachment to pulsating tools.

We recommend using our vibration dampers, according to ISO 6150 § 7.1.

Areas of application: Pneumatic system, machine and plant engineering, measurement, monitoring and control systems, manufacturing industry, medical technology, chemical / pharmaceutical industry, workshops, automotive.

"
Čas dobave 3 - 5 dni
21,75 €
Primerjaj z ostalimi
Šifra Povezava Pribor za pregrade a/f [mm] Dolžina [mm] Zaloga Cena Nakup Natisni
107231RIE I.D. 10 G 1/4 22 70.0
Čas dobave 3 - 5 dni
21,89 € Natisni
107230RIE I.D. 8 M12x1 22 62.0
Čas dobave 3 - 5 dni
21,75 € Natisni
107229RIE I.D. 6 M12x1 21 62.0
Čas dobave 3 - 5 dni
20,17 € Natisni

Opis

Quick-connect coupling I.D. 7.2, bright brass, Sleeve I.D. 8, Bulkhead thread M12x1, Operating pre. 0-35 bar, Temp. -20°C to 100°C

"

Universal, one-hand quick disconnect couplings, one side sealing, suitable for a wide range of tasks and applications!

The closed sleeve protects the coupling from dirt.

To prevent injuries or a ""whiplash"" effect, we recommend that the plug-in nipple is held with one hand during uncoupling.

These quick disconnect couplings are not suitable for direct attachment to pulsating tools.

We recommend using our vibration dampers, according to ISO 6150 § 7.1.

Areas of application: Pneumatic system, machine and plant engineering, measurement, monitoring and control systems, manufacturing industry, medical technology, chemical / pharmaceutical industry, workshops, automotive.

"

Tehnični podatki in specifikacije

DN 7.2
Povezava I.D. 8
a/f [mm] 22
Ohišje Brass with a bare metal surface
Tesnilo NBR
Min. temperatura medija [°C] -20
Max. temperatura medija [°C] 100
Min. sobna temperatura [°C] -20
Max. sobna temperatura [°C] 100
Pretok 1000 l/min (air)
Vzmet Stainless steel
Telo ventila Brass with a bare metal surface
Rokav Brass with a bare metal surface
Pritrdilni obroč Stainless steel
Zaporni zatič Stainless steel
Merjenje pretoka at 6 bar and Δp = 0.5 bar
Delovni tlak 0 to 35 bar, maximum static working pressure (non-pulsating)
Dolžina [mm] 62.0
Pribor za pregrade M12x1
